AS 800 FreeRider

Categories

Ride-on mower with limited slip differential for more traction

The AS 799 Rider’s big brother, the AS 800 FreeRider is equipped with a Briggs & Stratton Series 3 Intek engine with gear-reduction blade drive and up to 13.0 hp. With an AS cross-blade system and closed mowing deck, the AS 800 FreeRider cuts and mulches grass up to 80 cm high. The grass is then placed between the wheels and not run over, ensuring greater safety in wet conditions and on slopes. The cutting height can be adjusted to 4 levels between 35–85 mm. Hydrostatic transmission allows the precise adaptation of speed to match the terrain, reaching 8.0 km/h and 6.0 km/h in reverse while a limited slip differential can be switched on via a foot pedal. When in park, the mowing unit switches off automatically via a mechanical blade clutch.

The AS 800 FreeRider’s tubular frame ensures high stability; a bumper protects the axles and wheel suspension. A length-adjustable bucket seat provides a comfortable upright sitting position and ample legroom while a smooth steering system guarantees fatigue-free work.
Work rates up to 6,800 m² per hour are possible thanks to an 80 cm cutting height, powerful engine and hydrostatic transmission. A 15-litre tank means longer work periods without refueling. The AS 800 FreeRider is suited for both flat and uneven terrain and slight slopes.

Product advantages

Gear-reduction blade drive (AS 800)

Effortlessly mow grass up to 80 cm high with the gear-reduction blade drive.

Optimal all-terrain mobility

Field stud tyres, switchable limited slip differential and an engine suitable for slopes ensure powerful traction on difficult terrain.

Stable tube frame

High stability and torsional rigidity with heavy load.

Safety and convenience

Low centre of gravity and extended sitting position provide comfort and safety for tall operators.

Variable hydrostatic transmission (ride-on mower)

Easy adaptation of the speed to every terrain with integrated, mechanical parking brake in the drive lever.

Product details

product-image

AS mulching mower deck

Closed bearing-supported mower deck with AS cross-blade system. The main blade cuts high grass, the cross-blade shreds the cuttings.

product-image

Comfortable work

Comfortable sitting position, while a low centre of gravity and side deflectors provide additional safety.

product-image

Switchable limited slip differential

Convenient activation of limited slip differential via a foot pedal.

product-image

Cutting height

Four-level, central cutting height adjustment with automatic blade stop in transport position.

Warranty

At AS-Motor, we understand that professional users, municipalities, and property owners need more than just high-performance mowing technology – they need confidence in their investment. That’s why we go beyond industry norms to offer a warranty system that sets new standards in the landscaping sector.

Technical Data

cutting width 80 cm
engine manufacturer B&S
engine type Series 3 Intek
4-Stroke engine, single-cylinder / twin-cylinder /
displacement 344 cm³
work rate max. 9,7/13,0 kW (hp)
rated power 7,6/10,3 kW (hp)
nominal speed 3200 rpm
traction drive, 2WD rear / 4WD permanent /
traction drive, hydrostat variable
speed max. 8 km/h
limited-slip differential
automatic parking brake
Single knife / cross knife / Y-flail / /
side discharge / rear discharge /
closed mowing deck
cutting height 35 - 85 mm
ill quantity - fuel tank 15 l
seat suspention, standard / option /
Dimension L/W/H 170x87x96 cm
weight 231 kg
Changes in technology, equipment and price are reserved. Of information or illustrations no claims can be derived.

Accessories

product-image

Seat Suspension Kit (AS 915)

Seat suspension with improved progressive suspension, reinforced gas pressure damper and new end stop. Adjustable from 60-120 kg.

product-image

Lawn tyres

Tread suited for use on lawns.

product-image

Trailer

Cargo area: L = 1071 mm, W = 607 mm, panel height: 274 mm. Permissible total weight: 100 kg. Rear panel can be removed.

product-image

Trailer hitch Sherpa

To connect the AS trailer.

product-image

Snow blade

Width: 1107 mm, height: 348 mm. Pivots on both sides.

product-image

Snow chains

Cross-track chain for the drive wheels.
