AS 510 ProClip 2in1 2T A

2-stroke power for mowing and mulching on level ground and slopes

The AS 510 ProClip 2in1 2T A is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling work on inclines of 45 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque ensures that the power of the AS 510 ProClip 2in1 2T A is not interrupted.
A third crankshaft bearing and friction discs on the mulching blade protect the engine in the event of unseen obstacles. A variator allows the speed to be conveniently adjusted from 2.1–4.3 km/h while in motion. Double ball-bearing front wheels and rear wheel drive provide easy handling. The front wheels’ special wedge shape minimizes impact on the grass, leading to extremely uniform cutting results. Cutting height can be adjusted from 40–90 mm via a spring-supported system. Large, aggressive tread wheels offer ideal propulsion, even on slopes.

Mulching saves time and money

The specially-designed mulching blade cleanly cuts grass up to 18 cm high and simultaneously generates an airflow that whirls the cuttings in the mulching unit. The mulching blade’s multiple cutting edges chop and mulch the grass several times. The cuttings then sink into the turf, forming a layer of mulch that both fertilises and protects the lawn from drying out. The AS 510 ProClip 2in1 2T A saves 30% more time when compared with collection bag lawn mowers by avoiding the need to empty the collection bag as well as cost-intensive cuttings disposal.
Mow or mulch: The AS 510 ProClip 2in1 2T A is factory-equipped with an easy-to-mount mulch plate and side discharge deflector. Thus grass up to 50 cm high can be mowed with side discharge.

Product advantages

Engine suitable for slopes

The world's only AS 2-stroke engine with EasyStart has position-independent lubrication, ensuring safe operation even on steep slopes.

2in1 function

Mulch or mow with side discharge, the AS 510 2in1 can do both.

Up to 30% time saved

No collection basket, no cuttings disposal and fertilise the lawn simultaneously.

Blade shaft bearing arrangement protects the engine

Third crankshaft bearing and friction discs on the mulching blade ensure optimal engine protection.

Traction drive (AS 510)

Comfortable work through variable adjustable speed (variator) in conjunction with large, aggressive tread drive wheels for optimal traction.

Stable double frame

Stable tube frame with replaceable mulching unit.

Product details

Stable mulching unit

Closed and deep mulching unit for uniform results.

Cutting height adjustment

Central spring-supported height adjustment.

Special front wheels

Double ball-bearing supported, smooth-running wheels press down very little grass.

Operating bar

Stable bar height adjustment without tools.

Technical Data

cutting width 51 cm
maximum grass height "mulching" 40 cm
engine manufacturer AS-Motor
engine designation AS 165 ES
1-cyl.engine, 4-stroke / 2-stroke /
maximum power 4,4/6,0 kW (hp)
rated power 3,4/4,6 kW (hp)
rated speed 3000 rpm
blade clutch
third crankshaft bearing for engine protection
100% mulching function
additional side discharge
cutting height 40 - 90 mm
central cutting height adjustment
cutting height adjustment, number of levels 6
rear-wheel drive
number of gears Vario
max. speed 4,3 km/h
Handlebar adjustment: height
vibration-protect
tank capacity 5 l
dimension L/W/H 139x55x100 cm
weight 50 kg

Accessories

Operating hour meter

Documentation of work hours.

Tilt meter

Convenient display of slope incline.

Applications

Commercial landscaping

Performance on rough terrain, perfect cutting results and high efficiency are advantages AS-Motor machines provide to professional service providers.

Municipal maintenance

Caring for green areas in the civic environment involves a variety of tasks. From parks to roadside management, AS-Motor provides the correct tools to ensure both professional results and operator safety.

Gardening and landscaping

AS-Motor’s professional technology offers solutions for the diverse tasks of gardening and landscaping, from outdoor facilities to private gardens, public parks and residential lawns.

Road maintenance

Maintaining roadways often involves mowing high grass and slopes, two specialties of AS-Motor’s professional technology.

Private customers

When the goal is perfecting an ornamental lawn, obtaining forage for small animals or tending to the gardens and orchards of weekend homes, AS-Motor offers several professional mowing tools that will provide private users with excellent results for many years to come.

Utilities

AS-Motor offers professional technology for the maintenance of green spaces in and around public utility facilities.
