AS 940 Sherpa 4WD XL Loncin
High-grass, ride-on mower with permanent all-wheel drive and more ground clearance
The AS 940 Sherpa 4WD XL enables comfortable and safe mowing on slopes. A rated power of 21.2 hp at 708 cm3 is produced by the professional 2-cylinder OHV engine from Loncin. Its permanent all-wheel drive, XL tyres with field stud tread, low centre of gravity and low total weight of only 302 kg provide stability on slopes. Hydrostatic transmission allows the precise adaptation of speed to match the terrain, reaching 6.7 km/h and 6.5 km/h in reverse. Just one lever controls the drive, brake and parking functions for easy operation, while limited slip differential can be activated for excellent propulsion and traction in extreme situations. A brake pedal returns the drive lever to neutral and automatically engages the parking brake.
The AS 940 Sherpa 4WD XL’s surfing mower deck is equipped with AS cross-blade technology in which bearing-supported blades cut the grass, while a mulching blade positioned above them shreds the cuttings. The mulched grass is then deposited between the wheels for added safety on slopes and wet grass, while the mower deck’s surfing suspension yields upwards to obstacles, protecting the blades and turf from damage. With a 90 cm cutting width, the AS Sherpa 940 4WD XL achieves work rates reaching 5,500 m² per hour. Cutting heights can be adjusted to 5 levels from 80–135 cm and an optional mulch kit is available for even finer mulching results.
Maximum comfort for long work days
The AS 940 Sherpa 4WD XL performs even under harsh conditions thanks to its highly stable tubular frame. A length-adjustable seat and seat spring package mean operators up to 2 meters tall can operate the machine comfortably while a low centre of gravity, folding bar and branch deflectors are added safety features. Integrated lashing points enable secure transport.
Designed for continuous operation
Two separate ventilation circuits for the engine and hydrostatic transmission prevent overheating: the engine takes in air from above and discharges it to the side, while the hydrostatic transmission takes air from the rear and discharges it downward. This system ensures a long service life.
The all-wheel drive ride-on mowers from AS Motor in a new design
The 2023 all-wheel drive models of the AS Motor 940 Sherpa family will appear in new splendour in the future. With new paintwork, an additional front panel and the newly designed decals, the Sherpa’s are even more attractive. But the 2023 model year of the AS 4WD Sherpa family also offers some technical innovations.
The new ATV tyres on the AS 940 Sherpa XL and the remote-controlled ride-on mower AS 940 Sherpa RC feature even better performance when driving across slopes and better climbing ability. In future, all AS Motor 4WD Sherpa models will be equipped with the AS tyre sealant Plattfuss-Stop as standard – downtimes due to flat tyres will be a thing of the past. The new fuel tank of the Sherpas offers more volume (17 litres), a larger tank opening, a fuel level indicator and a closed circuit with less fuel evaporation. The new locking mechanism of the foldable bar ensures easier handling and improved freedom of movement when operating the driving lever. In future, the protective cloth between the engine and the seat will no longer be elaborately riveted, but locked in place by robust magnets. Accessibility to the engine, for example when adjusting the valves or changing the oil, is significantly improved. This was an idea from AS-Motor users and dealers. Many thanks for this practical improvement idea.
Permanent all-wheel drive ensures better traction uphill and stronger, safer braking downhill.
Closed mower deck with AS cross-blade system. The main blade cuts, the cross-blade chops the cuttings. The surfing mower deck gives way upward on uneven terrain to protect against damage.
Length-adjustable driver seat, innovative seat suspension and ergonomic sitting position provide comfort for tall operators during long work periods.
High stability and torsional rigidity with heavy load.
Field stud tyres, switchable limited slip differential and an engine suitable for slopes ensure powerful traction on difficult terrain.
Easy adaptation of the speed to every terrain with integrated, mechanical parking brake in the drive lever.
Greater operator safety in the machine's limit area.
AS mulching mower deck
Closed, surfing mower deck with cross-blade system and bearing-supported blades that yield to obstacles.
Separate air cooling supply
Separate engine air cooling and hydrostatic transmission optimize performance.
Switchable limited slip differential
Comfortable activation of the limited slip differential via foot pedal for excellent propulsion and traction.
XL tyres for 30 mm additional ground clearance.
Insect scare device
Scares insects and small animals away from the mower. Three times more insects can flee in time. With respective adapters suitable for AS 62/63, AS 701/901, AS Sherpa and AS YAK.More information »
Cargo area: L = 1071 mm, W = 607 mm, panel height: 274 mm. Permissible total weight: 100 kg. Rear panel can be removed.
Trailer hitch Sherpa
To connect the AS trailer.
Width: 1107 mm, height: 348 mm. Pivots on both sides.
Mulch kit – AS Sherpa
For even finer mulching and more uniform cutting results on lawns with grass up to 40 cm high.
Convenient display of slope incline.
Steering wheel knob
Optional for level terrain.
