AS 63 4T B&S

Modern Allmäher with high-performance engine for tall

Mowing and mulching in one step. Equipped with a cross-blade system and powered by a Briggs & Stratton engine with up to 5.0 hp, the AS 63 4T B&S easily cuts and shreds even high growth. A separate engine and blade shaft protect the engine in case of unseen obstacles. Variable drive enables speeds of 2.0–4.0 km/h. Work rates reaching 2,300 m² per hour are possible due to a high-performance Briggs & Stratton engine, variable drive and a 61 cm cutting width. The AS 63 4T B&S easily cuts grass up to 90 cm high. The drive-reduction transmission with a gear ratio of 1:13.44 allows the AS 63 4T B&S to brake autonomously when moving downhill. The machine will not speed up when moving downhill, no matter how steep the incline. The AS 63 4T B&S has a permanently locked limited slip differential while in drive, which increases traction and safety on slopes.

Convenient, safe and simple operation

The AS 63 4T B&S works with operating levers that activate the parking brake, the traction drive, the limited slip differential and the blade clutch. The automatic parking brake is an additional safety aspect. When the drive lever is released, the parking brake automatically engages and the AS 63 4T B&S stops, whether on a slope or level ground. For convenient operation the guide bar is equipped with a V-handlebar which can be adjusted laterally and for height without tools. “VibrationProtect” vibration damping reduces hand-arm vibration to a minimum.

Product advantages

Mow and mulch in one stepThe cross-blade system of the AS 63 Allmäher easily cuts and shreds high growth with an impressive cutting performance and excellent mulching result.
Automatic parking brakeWhen the drive lever is released the machine stops automatically, whether on a slope or level ground.
Self-braking traction driveThe drive-reduction transmission with a 1:13.44 gear ratio delivers optimal propulsion and brakes autonomously when moving downhill.
Automatic limited slip differential100% limited slip differential activates in drive, enabling better handling.
High cutting capacity (AS 63)1:1.6 engine-blade reduction for high cutting capacity in dense growth.
Engine protectionSeparate engine and blade shaft protects engine.
Conical mower deckConical mower deck generates an airflow that uniformly whirls the cuttings in the mulching unit, delivering excellent cutting results.

Product details

Variator

Speed regulator enables variable adjustment of the drive speed.

Vibration damping

"VibrationProtect" reduces hand-arm vibration to a minimum.

Easy transport

The AS 63 can be easily folded for compact transport dimensions.

Cleaning and service position

The compact design of the AS 63 enables easy and convenient cleaning.

Technical Data

cutting width 61 cm
maximum grass height 90 cm
engine manufacturer B&S
engine designation 850E I/C
displacement 190 cm³
maximum power 4,1/5,5 kW (hp)
rated power 3,7/5,0 kW (hp)
rated speed 3600 rpm
blade clutch
side discharge / rear discharge /
closed mowing deck
mono-blade / cross-blade / Y-flails / /
cutting height 50 - 100 mm
drive, mechanical/hydrostatic /
number of gears Vario
reverse gear
max. speed 3,8 km/h
limited-slip differential
automatic parking brake
steering brake
tank capacity 3 l
dimension L/W/H 191x70x99 cm
weight 74 kg

Accessories

Operating hour meter

Documentation of work hours.

Mulch kit AS 63

For even finer mulching and more uniform cutting results on lawns with grass up to 40 cm high.

Twin tyres AS 63

Optional twin tyres for improved traction on slopes with quick lock.

Applications

Private customers

When the goal is perfecting an ornamental lawn, obtaining forage for small animals or tending to the gardens and orchards of weekend homes, AS-Motor offers several professional mowing tools that will provide private users with excellent results for many years to come.

Meadow orchards

Meadow orchards characterize the landscape of diverse regions and provide valuable ecosystems for insect and bird life. Maintaining these areas often involves mowing around trees, on slopes and in rough terrain.

Commercial landscaping

Performance on rough terrain, perfect cutting results and high efficiency are advantages AS-Motor machines provide to professional service providers.

Equestrian businesses

Equestrian areas require various forms of green care. Whether maintaining paddocks or lawns, AS-Motor offers tools to create the ideal equestrian environment.

Viticulture

Viticulture, or wine-growing, is one of civilization's oldest forms of agriculture. AS-Motor was founded 60 years ago with the objective of tackling the slopes and thick growth of vineyards.

Leisure facilities

Leisure facilities must be visually appealing and expertly maintained. Whether parks or campsites, these areas are frequently used and thus require careful maintenance.
