AS 63 2T ES

Modern Allmäher for slopes and difficult terrain

Mulch where others hit their limits. The AS 63 2T ES is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling mowing on inclines of 45 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque provides full power in high, wet grass while a third crankshaft bearing and friction discs on the wing blade protect the engine in the event of striking an obstacle. Large inflatable tyres with field studs offer ideal propulsion at speeds up to 4.0 km/h. The drive-reduction transmission with a gear ratio of 1:13.44 allows the AS 63 2T ES to brake autonomously when moving downhill. The machine will not speed up when moving downhill, no matter how steep the incline. When in drive the AS 63 2T ES has a permanently locked limited slip differential which increases traction and safety, particularly on slopes. Work rates reaching 2,400 m² per hour are possible due to a high-performance 2-stroke engine with up to 6.7 hp, variable drive and a 61 cm cutting width. The AS 63 2T ES easily cuts grass up to 100 cm high.

Simple, convenient and safe operation

The AS 63 2T ES works with operating levers that activate the parking brake, the traction drive, the limited slip differential and the blade clutch. Absolute safety for slope mowing is achieved by an automatic parking brake and limited slip differential which remains permanently locked while the machine is in drive. When the drive lever is released, the parking brake automatically engages and the AS 63 2T ES stops, whether on a slope or level ground. For convenient operation the guide bar is equipped with a V-handlebar which can be adjusted laterally and for height without tools. “VibrationProtect” vibration damping reduces hand-arm vibration to a minimum.

Product advantages

Engine suitable for slopesThe world's only AS 2-stroke engine with EasyStart has position-independent lubrication, ensuring safe operation even on steep slopes.
Mow and mulch in one stepThe cross-blade system of the AS 63 Allmäher easily cuts and shreds high growth with an impressive cutting performance and excellent mulching result.
Automatic parking brakeWhen the drive lever is released the machine stops automatically, whether on a slope or level ground.
Self-braking traction driveThe drive-reduction transmission with a 1:13.44 gear ratio delivers optimal propulsion and brakes autonomously when moving downhill.
Automatic limited slip differential100% limited slip differential activates in drive, enabling better handling.
High cutting capacity (AS 63)1:1.6 engine-blade reduction for high cutting capacity in dense growth.
Engine protectionSeparate engine and blade shaft protects engine.
Conical mower deckConical mower deck generates an airflow that uniformly whirls the cuttings in the mulching unit, delivering excellent cutting results.

Product details

Variator

Speed regulator enables variable adjustment of the drive speed.

Vibration damping

"VibrationProtect" reduces hand-arm vibration to a minimum.

Easy transport

The AS 63 can be easily folded for compact transport dimensions.

Cleaning and service position

The compact design of the AS 63 enables easy and convenient cleaning.

Technical Data

cutting width 61 cm
maximum grass height 100 cm
engine manufacturer AS-Motor
engine designation AS 165 ES
displacement 165 cm³
maximum power 4,9/6,7 kW (hp)
rated power 4,5/6,1 kW (hp)
rated speed 3800 rpm
blade clutch
side discharge / rear discharge /
closed mowing deck
mono-blade / cross-blade / Y-flails / /
cutting height 50 - 100 mm
drive, mechanical/hydrostatic /
number of gears Vario
reverse gear
max. speed 4 km/h
limited-slip differential
automatic parking brake
steering brake
tank capacity 3 l
dimension L/W/H 191x70x99 cm
weight 77 kg

Accessories

Operating hour meter

Documentation of work hours.

Mulch kit AS 63

For even finer mulching and more uniform cutting results on lawns with grass up to 40 cm high.

Twin tyres AS 63

Optional twin tyres for improved traction on slopes with quick lock.

Applications

Private customers

When the goal is perfecting an ornamental lawn, obtaining forage for small animals or tending to the gardens and orchards of weekend homes, AS-Motor offers several professional mowing tools that will provide private users with excellent results for many years to come.

Commercial landscaping

Performance on rough terrain, perfect cutting results and high efficiency are advantages AS-Motor machines provide to professional service providers.

Meadow orchards

Meadow orchards characterize the landscape of diverse regions and provide valuable ecosystems for insect and bird life. Maintaining these areas often involves mowing around trees, on slopes and in rough terrain.

Gardening and landscaping

AS-Motor’s professional technology offers solutions for the diverse tasks of gardening and landscaping, from outdoor facilities to private gardens, public parks and residential lawns.

Utilities

AS-Motor offers professional technology for the maintenance of green spaces in and around public utility facilities.

Hunting and forestry

In forests and on hunting grounds, mowing can take place as infrequently as once per year or even at intervals of several years. AS-Motor machines are engineered to tackle the thick growth native to these areas as well as Christmas tree plantations.
